Home > Products > Instrument > Smelting Iron and Steel Temperature Measuring Instrument

Smelting Iron and Steel Temperature Measuring Instrument

  • Smelting Iron and Steel Temperature Measuring Instrument
  • Smelting Iron and Steel Temperature Measuring Instrument
  • Smelting Iron and Steel Temperature Measuring Instrument
  • Smelting Iron and Steel Temperature Measuring Instrument

Smelting Iron and Steel Temperature Measuring Instrument

    Payment Type: L/C,T/T,Paypal,Western Union
    Terms of Trade: FOB,CFR,CIF
    Min. Order: 1 Piece/Pieces
    Delivery Time: 15 Days
    Packaging: 1 piece / box
    Productivity: 10000 pcs/year
    Brand: QiRun
    Transportation: Ocean,Land,Air
    Place of Origin: Hebei,China(Mainland)
    Supply Ability: 10000 pcs/year
    Certificate: ISO 9001
    Port: Tianjin

Basic Info

Model No.: QR-SCW-98A

Product Description

Instrument on the front panel has a function selection switch, choose the working state of the instrument, when switch to rapid temperature measurement gear, instrument and rapid temperature measuring thermocouples used together, in the rapid temperature before, when the switch to continuous files, and supporting the use of the industrial thermocouple, continuous determine the temperature of the object to be tested.

Special remind users note: whenever this switch state changes, should make thermocouple signal input to open a or make instrument to electricity, the measurement condition to convert to is invalid.


Measuring Display Instrument

Technical Specification:

1.Measuring error:±0.2% ±1characters.

2.Working conditions:temperature 5-40°c relative humidity 85%

3.Storage conditions:temperature 0-45 °c relative humidity 85%

4.Power supply way:AC 220V ±10% ; Frequency:50HZ± 2Hz

5.Power loss approximately : 50W

Type

SW-98A

Thermocouple Type

S

Wre3/25

R

B

To test molten steel temperature range

1200°C-1769°C

1000°C-1999°C

1200°C1769°C

1200°C-1820°C

To test molten iron temperature range

900°C-1769°C

900°C-1999°C

900°C-1769°C

900°C-1820°C

To test molten copper temperature range

800°C-1769°C

800°C-1999°C

800°C-1769°C

800°C-1820°C

Continuous temperature-measuring range

0°C-1769°C

0°C-1999°C

0°C-1769°C

400°C-1820°C

Display

Super-bright LED display,

High character 127mm(5 inches)or liquid crystal display

Size

410mm*300mm*95mm

Weight

4kg

The acousto-optics alarm:

a.The gree light bright expression thermocouple puts through,the measuring appliance enters the preparation condition.

b.The yellow light brightly expressed the measuring appliance is surveying.

c.The red candle bright expressing survey process ended,at the same time the electric bell inspires the sound, 4-20mA or 1-5V analog output interface (specify when ordering), BCD at-large external display for the parallel interface

(specify when ordering),(Printer interface (specify when ordering).

Display Details

Display Details

Our Company

thermocouple factory yard


thermocouple workshop

testing equipment

pouring

warehouse

Certification

ISO9001


Our Customer

customer

foreign trader

Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, awe could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment .



Cangzhou Qi Run Detecting Instrument Co., Ltd., which was the former Nanpi XieLi Electronics Factory that was founded in 1996, is a professional production company for metallurgical industry detection, sensor and instrument. The company covers an area of 20000 square meters, construction area of 12000 square meters,and more than 200 employees. Qi Run owns many workshops sunch as stamping, machining, casting, paper tube, assembly, thermal instrumentation, research and other major production workshop.


More than 95% of the parts have achieved self-control, which effectively reduces the cost and enhances the competitiveness of us.


The molten steel sampler and fast thermocouple are the two key products for our company. Now our company Qi Run has achieved the annual production capacity which are listed below:

sampler 3 million each year,

sampler parts 5 million each year,

fast thermocouple 6 million each year,

oxygen probe 500 thousand each year.


Depending on strong technical force, advanced equipment, exquisite technology, continuous improvement of production management and quality assurance system, Qi Run is committed to the use of advanced technology for detection, sensing and research instrument manufacturing. The management of Qi Run is changing from quantity to quality and technology, and thoroughly executing the ISO9002 series standard.


In order to adapt to the needs of the development of metallurgical enterprises and industrial production automation control, the quality management is the main way to take the road of internationalization and enhance the competitiveness of the foundation.


Enterprise purpose: all for the customers

Enterprise philosophy: gather talent to service society, and synchronize with the world!


According to the development concept of [relying on scientific and technology, respect intellectual, pragmatic, pioneering and innovative", and depending on the enterprise purpose of[guided by technology, survived by quality, occupying the market with honesty, developing with good products", Cangzhou Qi Run Detecting Instrument Co.,Ltd never stops improving and innovating, and we will provide new products with better performance and higher quality for the majority of customers.


Qi Run will warmly welcome friends from all over the world to visit and guide, to discuss cooperation, to develop together, and to create a better tomorrow for the world!
